DIGITAL ELECTRONICS LABORATORY
| DEPARTMENT | NAME OF THE SUBJECT WITH COURSE CODE | SYLLABUS (NEW/OLD) | YEAR & SEMESTER |
|---|---|---|---|
| ECE | Digital System Design Lab (EC 392) | New | 2 nd Year 3rd Semester |
| CSE | Analog and Digital Electronics (ESC 391) (Digital Portion) | New | 2 nd Year 3rd Semester |
| EE | Digital electronics laboratory (PCEE-492) | New | 2 nd Year 4th Semester |
| CE | Basic Electronics (CE(ES)391)(Digital Portion:Mod-6) | New | 2 nd Year 3rd Semester |
- Simulation Setup using Verilog/VHDL.
- Digital IC Trainer Kit.
- Adder Circuit using Shift Registers.
- Logic Gate Trainer Kit.
- Excess-3 to Decimal Converter Kit.
- Trainer Kit for “Construction of Arithmetic Circuit Using Multiplexer”.
- Trainer Kit for “Asynchronous UP-DOWN Counter”.
- Digital to Analog Converter Kit.
- Trainer Kit for “4-bit Binary to Grey Code Converter”.
- Trainer Kit for “Study of Parity Circuits”.
- Trainer Kit for “Realization of Universal Register using Multiplexer”.
- Power Supply (Fixed 5V & Variable 12V).
- Multimeter.
- Breadboard and various discrete components with Digital IC.
